Factory Direct 22㎡ Mobile LED Trailer For Advertising

The design of JCT 22m² mobile LED trailer（Model：E-F22）is inspired by the Bumblebee in the movie “Transformers”. With bright yellow appearance, the trailer chassis is very wide and full of domineering. V-shaped design without any redundant decorations makes it simple but full of impact. The overall appearance is quite full with clean and agile lines and sharp edges and corners, giving people a heavy sense of security. In jingchuan trailer series, this trailer is also called "Bumblebee". Compared with other products in trailer series, 22m² mobile LED trailer has one more distinctive features that its trailer chassis can be choosed whether to equip with power system or not according to the needs of customers. If you choose a power chassis, an intelligent remote control handle is enough to move the trailer in short distance, and human or other traction forces can be saved in this way.Foldable screen Unique LED foldable screen technology brings customers a shocking and changeable visual experiences. Screen can play and fold at the same time. 360 degree barrier-free visual coverage and 22m² screen improve the visual effect. Meanwhile, as it effectively reduces the limits of transportation, it can meet the requirements of special regional dispatching and resettlement to expand the media coverage.Optional power, remote control The 22m² mobile LED trailer is optional with chassis power system and using manual and mobile dual braking. Intelligent remote control makes it more flexible. Solid rubber tire made of 16 manganese steel is safe and reliable.Fashionable appearance, dynamic technology The 22m² mobile LED trailer changed the traditional streamline design of previous products to a frameless design with clean and neat lines and sharp edges, fully reflecting the sense of science, technology and modernization. It is especially suitable for pop show, fashion show, automobile new product release and so on.Customized design LED screen size can be customized according to customer requests, other types like E-F16 (screen size 16m²) and E-F40 (screen size 40m²) are available. Product technical parameters 1. Overall dimension: 7800mm*1800mm*2940mm 2. LED outdoor full-color display screen (P6) size: 5760*3840mm 3. Lifting system: hydraulic cylinder imported from Italy with a stroke of 2000mm 4. Turning mechanism: hydraulic assistant of turning mechanism, bearing capacity: 3000KG 5. Power consumption (average consumption) : 0.3/m²/H, total average consumption. 6. Equipped with front-end video processing system for live broadcast or retransmission of programs and ball games, there are 8 channels, and the screen can be switched at will. 7. The intelligent timing power on system can turn on or off the LED screen regularly. 8, can be equipped with light control system to automatically adjust the brightness of LED display according to the light intensity. 9, equipped with multimedia playback system, support U disk playback, support mainstream video format, support circular playback, interstitials, timing playback and other functions. Input voltage 380V, starting current 35A.

Model	E-F22（22m² MOBILE LED TRAILER）
Chassis
Brand	JCT	External size	7800mm1800mm2940mm
Brake	Hand/Hydraulic	Total Weight	5300KG
Min. turning diameter	≥16m	Tire	Solid rubber tires
LED Screen
Screen Size	5760mm(W)*3840mm(H)	Dot Pitch	P3/P4/P5/P6
Lifespan	100,000hours
Hydraulic lifting System
Lifting System	Lifting range 2000mm
Supporting system	Range 300mm
Folding System	180 degree
Power parameter
Input Voltage	3 phases 5 wires 380V	Output Voltage	220V
Current	35A
Multimedia Control System
Video processor	Nova	Model	V900
Power amplifier	1500W	Speaker	200W*4pcs
