| Serial number | name | parameter |
| 1 | screen size | 480*1120mm |
| 2 | product model | FS5 |
| 3 | Point spacing | P5 |
| 4 | Pixel density | 40000 |
| 5 | LED lamp bead | 1R1G1B |
| 6 | LED lamp bead model | SMD1921 |
| 7 | Module size | 160*160mm |
| 8 | Module resolution | 32*32Px |
| 9 | Drive way | 1 / 8 sweep |
| 10 | angle of view (Deg) | H：140/V：140 |
| 11 | brightness | 5500 （cd/㎡） |
| 12 | grayscale | 14bit |
| 13 | refresh frequency | 1920Hz |
| 14 | Power consumption (w / ㎡) | Maximum power consumption: 760 / average power consumption: 260 |
| 15 | service life | 100000 hours |
| 16 | working voltage | AC 110V~220V+/-10% |
| 17 | Frame change frequency | 60Hz |
| 18 | Degree of protection | IP65 |
| 19 | working temperature | -30℃--+60℃ |
| 20 | Operating humidity (RH) | 10%-95% |
| 21 | Product certification | CCC、CE、ROHS |
